Specification
- Folded: 140×82×57 mm (L×W×H)
- Unfolded: 160×202×55 mm (L×W×H)
- Unfolded (with propellers): 245×290×55 mm (L×W×H)
- Diagonal Distance : 213 mm
- Max Ascent Speed
4 m/s (S Mode)
2 m/s (P Mode)
1.5 m/s (C Mode) - Max Descent Speed
3 m/s (S Mode)
1.8 m/s (P Mode)
1 m/s (C Mode) - Max Speed (near sea level, no wind)
13 m/s (S Mode)
8 m/s (P Mode)
4 m/s (C Mode) - Max Service Ceiling Above Sea Level : 3000 m
- Max Flight Time : 30 minutes (measured while flying at 14 kph in windless conditions)
- Max Wind Speed Resistance : 8 m/s (Scale 4)
- GNSS
- GPS+GLONASS
- Hovering Accuracy Range
- Vertical: ±0.1 m (with Vision Positioning), ±0.5 m (with GPS Positioning)
- Horizontal: ±0.1 m (with Vision Positioning), ±1.5 m (with GPS Positioning)
- Gimbal
- Mechanical Range
- Tilt: -110° to 35°
- Roll: -35° to 35°
- Pan: -20° to 20°
- Controllable Range
- Tilt: -90° to 0° (default setting) -90° to +20° (extended)
- Stabilization
- 3-axis (tilt, roll, pan)
- Max Control Speed (tilt)
- 120°/s
- Angular Vibration Range
- ±0.01°
Camera
- Sensor
- 1/2.3” CMOS
- Effective Pixels: 12 MP
- Lens
- FOV: 83°
- 35 mm Format Equivalent: 24 mm
- Aperture: f/2.8
- Shooting Range: 1 m to ∞
- ISO Range
- Video:
- 100-3200 (Auto)
- Photo:
- 100-1600 (Auto)
- 100-3200 (Manual)
- Shutter Speed
- Electronic Shutter: 4-1/8000s
- Still Image Size
- 4:3: 4000×3000
- 16:9: 4000×2250
- Still Photography Modes
- Single shot
- Interval: 2/3/5/7/10/15/20/30/60 s
- Video Resolution
- 2.7 K: 2720×1530 25/30 p
- FHD: 1920×1080 25/30/50/60 p
- Max Video Bitrate
- 40 Mbps
- Supported File System
- FAT32（≤32 GB）
- exFAT（>32 GB）
- Photo Format
- JPEG
- Video Format
- MP4 (H.264/MPEG-4 AVC）
Remote Controller & Video Transmission
- Operating Frequency
- Model MR1SS5: 5.725-5.850 GHz
- Model MR1SD25: 2.400-2.4835 GHz, 5.725-5.850 GHz
- Max Transmission Distance (unobstructed, free of interference)
- Model MR1SS5
- 5.8 GHz: 4000 m (FCC); 2500 m (SRRC)
- Model MR1SD25
- 2.4 GHz: 2000 m (MIC/CE)
- 5.8 GHz: 500 m (CE)
- Operating Temperature Range
- 0° to 40°C (32° to 104°F)
- Transmission Power (EIRP)
- Model MR1SS5
- 5.8 GHz: <30 dBm (FCC); <28 dBm (SRRC)
- Model MR1SD25
- 2.4 GHz: <19 dBm (MIC/CE)
- 5.8 GHz: <14 dBm (CE)
- Battery Capacity
- 2600 mAh
- Operating Current/Voltage
- 1200 mA 3.6 V (Android)
- 700 mA 3.6 V (iOS)
- Supported Mobile Device Size
- Max length: 160 mm
- Max thickness: 6.5-8.5 mm
- Supported USB Port Types
- Lightning, Micro USB (Type-B), USB Type-C
- Video Transmission System
- Enhanced Wi-Fi
- Live View Quality
- 720p/30fps
- Max. Bitrate
- 4 Mbps
